Product Features:
Steel Plate Structure Shot blast cleaning Machine for cleaning and strengthening metal surface,it can remove oxide mill and rust for different kind of steel profiles.
Widely used,high automation, auto feeding/discharging of workpiece, meeting request for production line.
Production Application:
Steel Plate Structure Shot blast cleaning Machine applies to shipping,car, motorcycle, bridge, machine industries etc. It mainly used for eliminating the stress and surface removing rust of large steel structure,H beam and so on.
We can design and manufacture all kinds of non-standard shot blasting machines
Q69 shot blasting machine | |||||
Parameter | Q698 | Q6912 | Q6915 | Q6920 | Q6925 |
The effective cleaning width (mm) | 800 | 1200 | 1500 | 2000 | 2500 |
Dimesion of inlet opening | 1600*800 | 1200*400 | 1700*400 | 2200*400 | 2700*800 |
The length of cleaning workpiece (mm) | 1200-12000 | 1200-12000 | 1200-12000 | 1200-12000 | 3000-12000 |
The speed of conveyor (m/min) | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 | 0.5-4 |
The thickness of cleaning steel sheet (mm) | 3-60 | 3-60 | 1.5-60 | 3-60 | 3-60 |
Shot ball flow rate (kg/min) | 4*120 | 4*250 | 4*250 | 6*250 | 6*250 |
The shot ball first loading (kg) | 4000 | 4000 | 4000 | 4500 | 4500 |
Roll brush adjusting height (mm) | 200 | 200 | 350 | 450 | 600 |
Air capacity (m3/h) | 22000 | 17560 | 19000 | 19550 | 27758 |
Total power (kw) | 90 | 78.3 | 113.5 | 156.6 | 204.8 |
